Fuel Filters
Customized Filters
Manufacturing Solution is here!
GDF-217
23303-87780/23303-87781
23300-87710
HEIGHT 118.0 mm
OUTER DIA 80.0 mm
THREAD M20X1.5 UNF
GASKIT INNER
BY PASS VALVE (PRESSURE) NO
ANTIDRAIN BACK VALVE NO
23401-1130/23401-1131
23401-1132
HEIGHT 77.0 mm
OUTER DIA 83.0 mm
THREAD M20X1.5 UNF
GASKIT INNER
BY PASS VALVE (PRESSURE) NO
ANTIDRAIN BACK VALVE NO
31973-44001
HEIGHT 138.0 mm
OUTER DIA 97.0 mm
THREAD M20X1.5 UNF
THREAD M36X1.5 UNF
GASKIT INNER
PACKING KIT
BY PASS VALVE (PRESSURE) NO
ANTIDRAIN BACK VALVE NO
31922-411001
HEIGHT 137.5 mm
OUTER DIA 87.5 mm
INNER DIA M1 6 X 1.5
GASKET INNER
ANTIDRAIN BACK VALVE NO
K71E-23-570
HEIGHT 121.0 mm
OUTER DIA 84.0 mm
THREAD M20X1.5 mm
THREAD M7/8X1.5UNF
GASKIT INNER BY PASS VALVE (PRESSURE) NO
ANTIDRAIN BACK VALVE NO
RF03-23-570/S213-23-570
HEIGHT 119.5 mm
OUTER DIA 95.0 mm
THREAD M20X 1.5 UNF
GASKIT INNER
BY PASS VALVE (PRESSURE) NO
ANTIDRAIN BACK VALVE NO
145623570A
HEIGHT 138.9 mm
OUTER DIA 93.7 mm
THREAD M20X1.5 UNF
M36X1.5 UNF
GASKIT INNER
PACKING KIT
BY PASS VALVE (PRESSURE) NO
ANTIDRAIN BACK VALVE NO
23303-24010
23303-64010
HEIGHT 141.5 mm
OUTER DIA 97.0 mm
THREAD 1) M20X1.5 UNF
THREAD 2) M36X1.5 UNF
GASKIT INNER PACKING KIT
BY PASS VALVE (PRESSURE) NO
ANTIDRAIN BACK VALVE NO
04234-68010
HEIGHT 73.0 mm
OUTER DIA 74.0 mm
INNER DIA 15.53 mm
GASKIT PACKING KIT
PACKING YES
23304-78110
HEIGHT: 112.0 mm
OUTER DIA: 104.2 mm
INNER DIA: 28.8 mm
GASKET PACKING KIT: YES
Fuel Filters
4052965
Height: 136mm
Diameter Top: 95mm
Thread Size: 1 1/16-16 UNF
GASKET INNER
BY PASS VALUE PRESSURE=NO
ANTI DRAIN BACK VALUE=NO
FF-1280/A-77470/3903410/3903410/11E1-70210/
673-271-6120/99912-03410
HEIGHT = 163.5 mm
OUTER DIA = 93.73 mm
THREAD = M20X1.5 UNF
SEAM DIA = 93.85 mm
GASKET INNER
BY PASS VALUE PRESSURE = NO
ANTI DRAIN BACK VALUE = NO
FF-185/CAT-IP-2299
HEIGHT = 176.28 mm
OUTER DIA = 93.47 mm
THREAD = 1-14UNF
SEAM DIA = 93.5 mm
GASKET-INNER
BY PASS VALUE PRESSURE = NO
ANTI DRAIN BACK VALUE = NO
26560163
HEIGHT = 116.3 mm
OUTER DIA = 76.1 mm
KIT = YES
GASKET PACKING KIT YES
BY PASS VALUE PRESSURE = NO
ANTI DRAIN BACK VALUE = NO
FF-5018/1174423/SW-3394/1160243/01160243/
5411316410/243004
HEIGHT = 125 mm
OUTER DIA = 77.5 mm
THREAD = M16X1.5
GASKET OUTER
BY PASS VALUE PRESSURE = NO
ANTI DRAIN BACK VALUE = NO
FF-1212/903941/3308638/4291867/11E-70220/
RE-42050/1214920-H1
HEIGHT 201.17 mm
OUTER DIA = 93.73 mm
THREAD=1-14 UNF
SEAM DIA= 94.5 mm
GASKET-INNER
BY PASS VALUE PRESSURE = NO
ANTI DRAIN BACK VALUE = NO
FF-5058
HEIGHT = 150.11 mm
OUTER DIA = 77.47 mm
THREAD = 3/4-16 UNF
SEAM DIA = 78.1 mm
GASKET OUTER
BY PASS VALUE PRESSURE = NO
ANTI DRAIN BACK VALUE = NO
FF-202299202
600-311-7132
HEIGHT = 287.24 mm
OUTER DIA = 120.20 mm
GASKET OUTER
BY PASS VALUE PRESSURE=NO
ANTI DRAIN BACK VALUE=NO
8-98092481-1
HEIGHT 188 mm
OUTER DIA 101 mm
INNER DIA 20.5 mm
GASKET PACKING KIT NO
8-98203599-0
HEIGHT: 116MM
OUTER DIAMETER TOP: 98MM
OUTER DIAMETER BOTTOM: 91MM
INSIDE DIAMETER: 12MM
GASKET PACKING KIT YES
NORTH BENZ 2534, 2536, 2532 (Model: 2012)
61260081334
HEIGHT: 170mm
OUTER DIAMETER TOP: 95MM
THREAD SIZE: M24X2
GASKIT INNER
23401-1730
Height: 193mm
Outer Diameter: 95mm
Inside Diameter: 27mm
GASKET PACKING KIT= YES
1117050A81DM
HEIGHT 261.0 mm
INNER DIA 117.8 mm
THREAD 1 1/4×16 UNF
GASKET OUTER
BY PASS VALVE (PRESSURE) NO
ANTIDRAIN BACK VALVE NO
PACKING YES
